Home Elevator

Home Elevator

Our company is also a leading manufacturer of home lifts that add style to your residence and has many features to it. The technology that these lifts use is quite eco-friendly and saves a lot of energy.
This product is designed and manufactured according to the needs of the clients and as per his pocket too.

TABLE OF DIMENSION

PERSONS LOAD (KG) CAR-INSIDE LIFT-WELL ENTRANCE CLEAR OPENING FOR DOOR FRAME DOOR FRAME HEIGHT
A B C D E F STANDARD
4 272 900 900 1400 1500 700(Min.) 1175 2290
6 408 1000 1100 1500 1700 700(Min.) 1175 2290
8 544 1300 1100 1900 1700 800 1275 2290
10 680 1300 1350 1900 1950 800 1275 2290
13 884 2000 1100 2500 1700 900 1350 2290
